Description
The ASUS PRO WS TRX50-SAGE WIFI A is part of ASUS’s workstation motherboard range and is designed for users who need a professional-grade platform for heavy compute and multi-device workloads. It uses the AMD TRX50 chipset and Socket sTR5, supporting both Ryzen Threadripper 7000 and 9000 Series processors as well as Threadripper PRO 7000 and 9000 WX-Series processors. The board is built around a large workstation-focused layout with support for ECC RDIMM memory, multiple full-length PCIe slots for GPUs, storage cards, or accelerator cards, and strong onboard connectivity for professional environments. It also includes advanced cooling support, multiple M.2 slots, SlimSAS NVMe capability, 10Gb and 2.5Gb Ethernet, and ASUS workstation management features, making it suitable for advanced creator and enterprise-focused desktop workstations.
Specifications
Chipset: AMD TRX50
Socket: AMD Socket sTR5
CPU support: AMD Ryzen Threadripper 9000 Series, Ryzen Threadripper 7000 Series, Ryzen Threadripper PRO 9000 WX-Series, Ryzen Threadripper PRO 7000 WX-Series
Form factor: SSI-CEB / workstation-class large board layout
Power design: 36 power stages
Memory type: DDR5 ECC Registered DIMM
Memory support: 4 x DIMM slots
Maximum memory: Up to 1TB
Memory architecture: Quad-channel
Memory overclocking support: Up to DDR5-6400 (OC), depending on CPU and memory configuration
Memory profile support: AMD EXPO for supported ECC RDIMM modules
Primary expansion slots: 2 x PCIe 5.0 x16
Additional expansion slots: 1 x PCIe 5.0 x16 operating at x8, 1 x PCIe 4.0 x16, 1 x PCIe 4.0 x16 operating at x4
Storage: 3 x M.2 slots
M.2 support: PCIe 5.0 x4 and PCIe 4.0 x4 depending on slot
Additional storage: 4 x SATA 6Gb/s
Enterprise storage support: 1 x SlimSAS slot with PCIe 4.0 x4 NVMe support
Ethernet: 1 x 10Gb Ethernet
Ethernet: 1 x 2.5Gb Ethernet
Wireless: WiFi 7
Bluetooth: Bluetooth 5.4
Rear USB: 1 x USB 20Gbps Type-C
Rear USB: 6 x USB 10Gbps Type-A
Rear USB: 2 x USB 2.0 Type-A
Front USB support: 1 x USB 20Gbps Type-C connector with up to 30W power delivery
Front USB support: 1 x USB 10Gbps Type-C header
Front USB support: 1 x USB 5Gbps header
Front USB support: 2 x USB 2.0 headers
Display outputs: 1 x DisplayPort
Display outputs: 1 x HDMI
Audio: High-definition audio
Rear audio: 2 x audio jacks
Optical audio: 1 x Optical S/PDIF out
Cooling support: CPU fan, CPU OPT, AIO pump, and multiple chassis fan headers
Special features: BIOS FlashBack, workstation management support, ASUS Control Center support, IPMI expansion card support, Aura Sync, onboard buttons and diagnostics for workstation setup
