Name: Trendnet 48V 120W Single Output Industrial DIN-Rail Power Supply
Brand: Trendnet
SKU: SKU-393
Availability: InStock

Trendnet 48V 120W Single Output Industrial DIN-Rail Power Supply

R600.00

The TRENDnet TI-S12048 is a high-efficiency 120W industrial-grade DIN-rail power supply designed to deliver reliable 48V DC output for use with network switches, access points, IP cameras, and other industrial networking equipment. Engineered for harsh environments, it ensures stable operation across a wide temperature range and features multiple layers of protection.

SKU: SKU-393 Category: Adapter's Brand: Trendnet

Description

Technical Specifications:

Model: TI-S12048
Output Power: 120W
Output Voltage & Current: 48V DC @ 2.5A
Input Voltage Range:
- AC: 100–240V AC, 50/60 Hz, 1.8A
- DC: 125–370V DC
Efficiency: Up to 91%
Active PFC (Power Factor Correction): Yes, >0.93
Certifications: UL 508, TUV EN60950-1, CE
Protection Features:
- Overload Protection
- Over-Voltage Protection
- Short Circuit Protection
- Over-Temperature Protection
MTBF (Mean Time Between Failures): >2,899,000 hours
Cooling Method: Natural air convection (fanless)
DC OK Relay Output: Yes (for remote monitoring)
Peak Load Capacity: Supports up to 150% peak power for short durations

Physical & Environmental:

Mounting: DIN-Rail
Dimensions: 40 × 125 × 114 mm
Weight: Approx. 670 g
Operating Temperature: -25°C to 70°C
Storage Temperature: -40°C to 85°C
Humidity (non-condensing): 5% to 95%

Key Features:

Industrial Reliability: Designed for continuous operation in demanding conditions such as manufacturing plants, transport facilities, and outdoor enclosures.
DIN-Rail Mountable: Simple integration into industrial control panels or networking enclosures.
Compact Form Factor: Saves space in tight installations while maintaining excellent thermal performance.
Fanless Operation: Reduces maintenance needs and operational noise, ideal for sensitive environments.
Status Monitoring: Integrated LED indicators and relay contact for DC OK notification.
