Description
🧩 Hardware Specifications:
-
Total Ports:
-
24 × 10/100/1000 Mbps RJ45 Ethernet ports
-
4 × 10 Gbps SFP+ slots (for fiber uplinks or high-speed stacking)
-
1 × RJ45 console port
-
1 × Micro-USB console port
-
-
Switching Capacity: 128 Gbps
-
Forwarding Rate: 95.23 Mpps
-
MAC Address Table: 16,000 entries
-
Packet Buffer Memory: 12 Mb
-
Jumbo Frame Support: Up to 9,216 bytes
-
Power Supply: Internal AC input (100–240V ~ 50/60 Hz)
-
Power Consumption:
-
Max: 23.6 W
-
Standby: Approx. 8.67 W
-
-
Cooling: Fanless (silent operation)
-
Chassis: Metal, rack-mountable
-
Dimensions: 440 mm × 180 mm × 44 mm
-
Weight: Approx. 2.5 kg
🌐 Software & Network Features:
Layer 2 Features:
-
802.1Q VLAN (supports up to 4,000 VLANs)
-
VLAN Group Management
-
Spanning Tree Protocol (STP/RSTP/MSTP)
-
Link Aggregation Control Protocol (LACP)
-
IGMP Snooping v1/v2/v3
-
Port Isolation
-
Loopback Detection
-
Port Mirroring
Layer 3 Features:
-
Static Routing (IPv4 & IPv6)
-
Up to 48 static routes
-
DHCP Server / DHCP Relay
Quality of Service (QoS):
-
8 hardware priority queues
-
802.1p/DSCP CoS support
-
Traffic scheduling algorithms: SP, WRR, SP+WRR
-
Rate limiting per port or per flow
Security Features:
-
802.1X Port Authentication
-
Access Control Lists (L2~L4 filtering)
-
IP-MAC-Port Binding
-
DHCP Snooping
-
ARP Inspection
-
Storm Control (Broadcast, Multicast, Unknown-Unicast)
-
Port Security (limits number of devices per port)
-
DoS Defense
Management:
-
Omada SDN integration (centralized cloud-based control)
-
Web-based GUI for local access
-
Command Line Interface (CLI) via Telnet or console
-
SNMP v1, v2c, v3
-
RMON (Groups 1, 2, 3, 9)
-
Dual Image Support
-
System Logging and Real-Time Monitoring
-
NTP synchronization
🌡️ Environmental & Reliability:
-
Operating Temperature: 0°C to 45°C
-
Storage Temperature: –40°C to 70°C
-
Operating Humidity: 10%–90% RH (non-condensing)
-
Storage Humidity: 5%–90% RH (non-condensing)
