Description
Key Features:
- 80 PLUS Gold Certification: Ensures up to 90% efficiency, reducing power consumption and heat output.
- Fully Modular Design: Allows for customized cable management, improving airflow and aesthetics.
- Ultra-Quiet 140mm Hydraulic Bearing Fan: Provides efficient cooling while maintaining low noise levels.
- Smart Zero Fan Mode: Keeps the fan off at low loads (<20%), ensuring silent operation.
- Premium Japanese 105°C Capacitors: Enhances durability and stable power delivery.
- Low Ripple Noise: Keeps ripple below 30mV on major rails (+12V, +5V, +3.3V), ensuring component longevity.
- Strict Voltage Regulation: Maintains voltage fluctuations within ±2%, ensuring reliable system performance.
Specifications:
- Maximum Output Capacity: 850W
- Peak Output Capacity: 1020W
- Dimensions: 150mm (W) x 86mm (H) x 160mm (D)
- Power Factor Correction (PFC): Active PFC
- Power Good Signal: 100-500 milliseconds
- Hold-Up Time: >16 milliseconds at 100% full load
- Input Voltage: 100V – 240V~
- Input Frequency Range: 50Hz – 60Hz
- Input Current: 12A
- Operating Temperature: 0°C to +50°C
- Operating Humidity: 20% to 90%, non-condensing
- Storage Temperature: -20°C to +70°C
- Storage Humidity: 5% to 95%, non-condensing
- Cooling System: 140mm Hydraulic Bearing Fan
- Efficiency: Meets 80 PLUS Gold standards at 115V input
- MTBF (Mean Time Between Failures): 120,000 hours minimum
- Safety Certifications: CE, cTUVus, TÃœV SÃœD, FCC, BSMI, EAC
Connectors:
- Main Power (24Pin): 1
- ATX 12V (4+4Pin): 2
- PCI-E (6+2Pin): 6
- SATA Power: 8
- Peripheral (4Pin): 4
- Floppy Drive Adapter: 1
Protection Features:
- Over Current Protection (OCP)
- Over Voltage Protection (OVP)
- Under Voltage Protection (UVP)
- Over Power Protection (OPP)
- Short Circuit Protection (SCP)
- Over Temperature Protection (OTP)
This 850W PSU is an excellent choice for gaming PCs and workstations, offering high efficiency, quiet operation, and modular flexibility, making it ideal for high-performance builds.
