Description
Key Features:
- Intel ATX 3.0 Compliance: Supports up to 200% power excursion, ensuring compatibility with the latest hardware and high-power demand components.
- 80 PLUS Gold Certification: Ensures up to 90% efficiency, reducing energy consumption and heat output.
- Fully Modular Design: Allows for clean cable management, improving airflow and aesthetics.
- Native PCIe Gen 5.0 12VHPWR Connector: Features a 16-pin (12+4) connector capable of delivering up to 450W, supporting next-gen GPUs.
- High-Quality Japanese Capacitors: Enhances power stability, efficiency, and durability.
- Ultra-Quiet Cooling: 120mm fluid dynamic bearing (FDB) fan for efficient cooling and silent operation.
Specifications:
- Maximum Output Capacity: 850W
- Dimensions: 150mm (W) x 86mm (H) x 140mm (D)
- Power Factor Correction (PFC): Active PFC
- Input Voltage: 100 – 240V AC
- Input Frequency Range: 50Hz – 60Hz
- Input Current: 10A Max.
- Operating Temperature: 0°C to +45°C
- Operating Humidity: 5% to 85%, non-condensing
- Cooling System: 120mm Fluid Dynamic Bearing (FDB) fan
- Efficiency: Meets 80 PLUS Gold standards at 115V input
- MTBF (Mean Time Between Failures): 100,000 hours minimum
- Safety Approvals: CE, FCC, UKCA, ICES, LVD, TUV, cTUVus, CB, CCC, BSMI
Connectors:
- Main Power (24Pin): 1
- ATX 12V (4+4Pin): 2
- PCIe (6+2Pin): 4
- PCIe (12+4Pin) 450W: 1
- SATA (5Pin): 8
- Peripheral (4Pin): 4
- FDD Adapter: 1
Protection Features:
- Over Current Protection (OCP)
- Over Voltage Protection (OVP)
- Under Voltage Protection (UVP)
- Over Power Protection (OPP)
- Short Circuit Protection (SCP)
- Over Temperature Protection (OTP)
This 850W PSU is optimized for high-performance gaming PCs and next-gen hardware, offering stable power delivery, energy efficiency, and future-proof connectivity with PCIe 5.0 and ATX 3.0 compatibility.
