Description
-
🧰 Specifications
-
Case Type: Mid-Tower
-
Dimensions: 541 × 259.5 × 547 mm
-
Weight: Approx. 19 kg
-
Material Composition: SGCC Steel, Tempered Glass, ABS, Nylon, Zinc Alloy, NdFeB Magnets
-
Motherboard Support: E-ATX (up to 277 mm wide), ATX, Micro-ATX, Mini-ITX
-
Expansion Slots: 6 Horizontal
-
GPU Clearance: Up to 470 mm length, 195 mm height, 4-slot thickness
-
CPU Cooler Clearance: Up to 185 mm
-
Power Supply Support: ATX, SFX, SFX-L (Max length: 220 mm)
-
Storage Options:
-
4 × 3.5″ drive bays
-
8 × 2.5″ SSD mounts (side)
-
1 × 3.5″ or 2 × 2.5″ (cable tray mount)
-
-
Fan Support:
-
Top: 3 × 120/140 mm
-
Side: 3 × 120/140 mm
-
Bottom: 3 × 140 mm
-
Rear: 2 × 120/140 mm
-
-
Radiator Support:
-
Top: Up to 420 mm
-
Side: Up to 420 mm
-
-
I/O Ports:
-
1 × USB 3.2 Gen 2 Type-C
-
2 × USB 3.2 Gen 1 Type-A
-
1 × 3.5 mm combo audio jack
-
Power and Reset buttons
-
-
Dust Filters: Magnetic or removable filters at top, bottom, side, and rear bottom
-
Cable Management: SimpliCable routing system with integrated PWM fan hubs
-
Pre-installed Fans: None
🔍 Key Features
-
UniSheet Tempered Glass: Single bent panel for front and side, offering full component visibility
-
Modular Dual-Chamber Layout: Clean internal separation of airflow zones
-
Chimney-Style Airflow: Optimized for vertical heat exhaust and high fan density
-
Robust Cable Management: Includes labeled routing paths and secure clips
-
Optional Display Mount: VESA-compatible internal bracket for screen or AIO reservoir
-
Included Accessories: ESD-safe gloves, hardware organizer, and GPU support bracket (for horizontal mounting)
🚫 VGPU Kit Not Included
This version does not include:
-
Vertical GPU mount hardware
-
PCIe riser cable
-
Angled airflow bottom fan bracket
-
Special airflow-directing internal glass plate
Instead, it uses a horizontal GPU anti-sag bracket supporting GPUs up to ~300 mm effectively, depending on cooler and slot height.
-
