B650M PROJECT ZERO

Description

Specifications:

CPU Support:

• AMD Ryzen 8000 / 7000 Series

• AM5 Socket

• 12+2+1 Power Phase with extended heatsinks and rear power connector layout

Memory:

• 4× DDR5 DIMM slots

• Supports up to 192GB

• Up to 7600+ MHz (OC)

• Dual-channel with AMD EXPO support

Graphics Output:

• 1× HDMI 2.1

• 1× DisplayPort 1.4

• Supports integrated graphics (G-series CPUs)

Expansion Slots:

• 1× PCIe 4.0 x16

• 1× PCIe 3.0 x1

Storage:

• 2× M.2 Slots

  • 1× PCIe 4.0 x4 (with M.2 Shield Frozr)

  • 1× PCIe 4.0 x2

• 4× SATA 6Gb/s Ports

• RAID 0/1/10 support

Networking:

• Realtek 2.5G LAN

• Wi-Fi 6E

• Bluetooth 5.3

Audio:

• Realtek ALC897

• 7.1 Channel HD Audio

Other Features:

• Rear-positioned power connectors (Project Zero layout)

• USB 3.2 Gen 2×2 Type-C

• USB 3.2 Gen 2, Gen 1, USB 2.0

• ARGB + RGB headers

• Debug LED

• BIOS Flash Button

• Pre-installed I/O shield

---

Ideal For:

• Modern SFF and mid-tower builds

• Clean cable management enthusiasts

• Builders prioritizing aesthetics without compromising performance
