Description
ASUS Motherboard/The ASUS PRIME H810M-A WIFI is part of the ASUS Prime motherboard range and is designed as a compact foundation for Intel LGA 1851 desktop builds. It supports Intel Core Ultra Series 2 processors, DDR5 memory, and PCIe 4.0 for both graphics and NVMe storage, making it suitable for home, office, and mainstream custom systems. Its micro-ATX design helps it fit into more compact cases while still offering essential expansion, onboard wireless connectivity, multiple display outputs, and front USB support. It is aimed at users who want a current-generation Intel platform with balanced features, straightforward connectivity, and a practical overall design.
Specifications
Chipset: Intel H810
Socket: Intel LGA 1851
CPU support: Intel Core Ultra Processors (Series 2)
Form factor: micro-ATX
Power design: 6+1+1+1 phase digital power design
Memory type: DDR5
Memory support: 2 x DIMM slots
Maximum memory: 128GB
Memory architecture: Dual-channel
Memory speed support: Up to 6400 MT/s, depending on CPU and memory configuration
Memory profile support: Intel XMP, ASUS AEMP II, DIMM Fit
Primary graphics slot: 1 x PCIe 4.0 x16
Additional expansion slot: 1 x PCIe 4.0 x1
Storage: 2 x M.2 slots
Primary M.2 support: PCIe 4.0 x4 NVMe
Secondary M.2 support: PCIe 4.0 x2 NVMe
SATA: 4 x SATA 6Gb/s
Ethernet: 1Gb Ethernet
Wireless: WiFi 6
Display outputs: 1 x DisplayPort
Display outputs: 1 x HDMI
Rear USB: 2 x USB 10Gbps Type-A
Rear USB: 4 x USB 2.0 Type-A
Front USB support: 1 x USB 5Gbps header
Front USB support: 1 x front USB Type-C connector
Front USB support: 1 x USB 2.0 header
Audio: 3 x audio jacks
Rear legacy I/O: 1 x PS/2 combo port
Cooling features: VRM heatsink, chipset heatsink, CPU fan header, chassis fan headers
Lighting support: Addressable Gen 2 RGB headers, Aura Sync
Special features: SafeSlot Core+, Q-LED Core
