Description
The ASUS ROG MAXIMUS Z890 EXTREME is a flagship E-ATX motherboard built for Intel Core Ultra desktop processors on the LGA 1851 socket. It uses the Intel Z890 chipset and is aimed at ultra-premium gaming, overclocking, and workstation-class enthusiast systems. This model sits at the top of the range with a very high-end power design, extensive cooling hardware, premium onboard features, and unusually broad connectivity for demanding builds.
It supports DDR5 memory, multiple PCIe 5.0 expansion paths, and a large amount of high-speed storage through several M.2 slots plus SATA. Networking is a major highlight, with Wi-Fi 7 and dual wired LAN including 10GbE. The board also stands out for its enthusiast-focused design elements such as advanced memory tuning features, onboard convenience controls, tool-free installation features, premium audio, and a built-in display for monitoring and customization. It is designed for users building a no-compromise Intel platform with strong expansion, storage, and connectivity.
Model: ASUS ROG MAXIMUS Z890 EXTREME Form factor: E-ATX Chipset: Intel Z890 Socket: LGA 1851 CPU support: Intel Core Ultra desktop processors
Memory: 4 x DDR5 DIMM slots Maximum memory capacity: Up to 256GB Memory support: Up to DDR5-9200+ OC Supports XMP Supports AEMP III Supports DIMM Flex Supports DIMM Fit Supports NitroPath DRAM Technology
Expansion slots: 2 x PCIe 5.0 x16 slots 1 x PCIe 4.0 x4 slot Multi-slot lane sharing supported depending on M.2 configuration
Storage: Up to 6 x M.2 slots Multiple PCIe 5.0 M.2 slots Additional PCIe 4.0 M.2 support 4 x SATA 6Gb/s ports
Networking: Wi-Fi 7 Bluetooth support 1 x 10Gb Ethernet 1 x 2.5Gb Ethernet
Rear I/O: 2 x Thunderbolt 5 USB Type-C ports 1 x USB 20Gbps Type-C port 7 x USB 10Gbps ports 1 x HDMI Wi-Fi antenna connectors Audio jacks Optical S/PDIF out BIOS FlashBack button Clear CMOS button
Audio: ROG SupremeFX audio High-definition onboard audio design Premium DAC implementation
Power and cooling: High-end multi-phase VRM design Large VRM and M.2 heatsinks Designed for heavy-load and overclocked operation
Other features: Built-in display for hardware monitoring and customization PCIe 5.0 graphics support Advanced AI overclocking features AI cooling features AI networking features Q-Release and tool-free installation features Aura Sync lighting support Onboard enthusiast controls and diagnostics
