Description
The ASUS ROG STRIX Z890-F GAMING WIFI is part of ASUS’s premium ROG Strix motherboard lineup and is built for users who want a modern Intel platform with strong tuning, cooling, and connectivity options. Its ATX layout provides room for multiple expansion devices, five onboard M.2 storage options, and broad cooling support, making it suitable for advanced gaming systems, creator PCs, and enthusiast desktop builds. The board supports DDR5 memory, a PCIe 5.0 x16 graphics slot, integrated WiFi 7, dual Thunderbolt 4 ports, high-speed USB connectivity, and premium onboard audio, while also including ASUS DIY-friendly features for easier installation, upgrading, and tuning.
Specifications
Chipset: Intel Z890
Socket: Intel LGA 1851
CPU support: Intel Core Ultra Processors (Series 2)
Form factor: ATX
Memory type: DDR5
Memory support: 4 x DIMM slots
Maximum memory: Up to 256GB
Memory architecture: Dual-channel
Memory overclocking support: Up to DDR5-9066+ MT/s (OC)
Memory profile support: Intel XMP
Memory tuning features: DIMM Flex, DIMM Fit, ASUS AEMP III
Primary graphics slot: 1 x PCIe 5.0 x16
Lane mode support: x16 or x8/x4/x4
Additional expansion slot: 1 x PCIe 4.0 x16 operating at x4
Storage: 5 x M.2 slots
Primary M.2 support: 1 x PCIe 5.0 x4 NVMe
Additional M.2 support: 4 x PCIe 4.0 x4 NVMe
SATA: 4 x SATA 6Gb/s
Ethernet: Intel 2.5Gb Ethernet
Wireless: WiFi 7
Bluetooth: Bluetooth support
Rear USB: 2 x Thunderbolt 4 USB Type-C
Rear USB: USB 10Gbps Type-A connectivity
Rear USB: USB 10Gbps Type-C connectivity
Rear USB: USB Type-C with up to 30W PD fast charging
Rear USB: USB 5Gbps Type-A connectivity
Rear USB: USB 2.0 Type-A connectivity
Display outputs: 1 x HDMI
Audio: ROG SupremeFX 7.1 high-definition audio
Special features: BIOS FlashBack, Clear CMOS, PCIe Slot Q-Release Slim, M.2 Q-Latch, ASUS WiFi Q-Antenna, Aura Sync RGB
