Description
๐งฐ Case Type & Compatibility
-
Case Type: Mini-Tower / Vertical Mini-ITX
-
Motherboard Support:
-
Mini-ITX
-
Mini-DTX
-
-
Orientation: Dual-mode โ can be used vertically or horizontally
-
Expansion Slots: 3 (for vertical GPU mount)
-
Drive Bays:
-
3 x 2.5″ SSD
-
2 x 2.5″/3.5″ combo bays
-
๐ Build & Dimensions
-
Frame Material: High-quality SPCC steel
-
Side Panels:
-
2 x Tempered glass (front and side)
-
2 x Aluminum panels
-
-
Color: Matte black with ROG styling and illuminated logo
-
Size (W x D x H): 194 x 386 x 531 mm
-
Weight: Approx. 8.7 kg
โ๏ธ Cooling Support
-
Pre-installed Fans:
-
2 x 140 mm (bottom)
-
1 x 140 mm (top)
-
-
Fan Support:
-
Top: 1 x 120/140 mm
-
Bottom: 2 x 120/140 mm
-
Rear: 1 x 120 mm
-
Side: 2 x 120 mm
-
-
Radiator Support:
-
Rear: Up to 120 mm
-
Side: Up to 240 mm (slim profile recommended)
-
-
Airflow Design: Patented 11ยฐ tilted layout improves airflow and cable routing
๐ Component Clearance
-
GPU Length: Up to 320 mm
-
CPU Cooler Height: Up to 130 mm
-
PSU Support: ATX PSU up to 160 mm
๐ Front I/O Ports
-
1 x USB 3.2 Gen 2 Type-C
-
2 x USB 3.2 Gen 1 Type-A
-
2 x USB 2.0
-
1 x HD Audio Jack
-
Aura Sync button (controls built-in RGB)
๐ก Lighting & Style
-
Integrated RGB: ROG logo and front light bar
-
Aura Sync Compatible: Yes โ syncs with ASUS ecosystem
-
Cable Management: Rear routing channels with Velcro straps
-
Vertical GPU Mounting: Supported (PCIe riser cable included)
๐ฏ Best For
-
Compact yet powerful builds
-
ROG fans looking for a showcase system
-
Users needing efficient airflow in small form factor
-
Vertical setups with water cooling or custom loops ๐ง๐ฎ๐ก
