🛡️ ASUS Prime X670-P Wi-Fi – ATX Motherboard

Description

🧠 Processor Compatibility

• Socket: AM5

• Chipset: AMD X670

• Supported CPUs: AMD Ryzen™ 7000 Series Desktop Processors

• Architecture: Zen 4

---

🛠️ Power Design

• VRM Configuration: 12+2 DrMOS power stages

• Power Connectors: 8+4 pin ProCool

• PCB Layers: 6-layer PCB

• Cooling Enhancements: Enlarged VRM heatsinks with thermal pads

---

💾 Memory Support

• Memory Type: DDR5

• Slots: 4 x DIMM

• Max Capacity: Up to 128 GB

• Speed: Up to 6400+ MT/s (OC)

• Features: Dual-channel architecture, AMD EXPO™ profile support, OptiMem II signal optimization

---

🎮 Expansion Slots

• 1 x PCIe 4.0 x16 (SafeSlot Core+ reinforced)

• 2 x PCIe 4.0 x16 (x4 mode)

• 1 x PCIe 3.0 x1

---

📦 Storage Options

• M.2 Slots:

  • 1 x PCIe 5.0 x4 (2280)

  • 1 x PCIe 4.0 x4 (22110)

  • 1 x PCIe 4.0 x4 (2280)

• SATA: 4 x SATA 6Gb/s ports

• RAID Support: RAID 0, 1, 10 on NVMe and SATA

---

🎨 Integrated Graphics Outputs

(Requires a Ryzen CPU with integrated graphics)

• 1 x HDMI 2.1 (up to 4K@60Hz)

• 1 x DisplayPort 1.4 (up to 4K@60Hz)

---

🌐 Networking

• Ethernet: Realtek 2.5Gb LAN

• Wireless: Wi-Fi 6 (802.11ax, dual-band 2×2)

• Bluetooth: Version 5.2

---

🔌 USB Connectivity

Rear I/O:

• 1 x USB 3.2 Gen 2×2 Type-C (20Gbps)

• 3 x USB 3.2 Gen 2 Type-A (10Gbps)

• 4 x USB 3.2 Gen 1 Type-A (5Gbps)

• 2 x USB 2.0 Type-A

• 1 x HDMI

• 1 x DisplayPort

• 1 x Realtek 2.5Gb LAN

• 3 x Audio jacks

Internal Headers:

• 1 x USB 3.2 Gen 1 Type-C (front panel)

• 2 x USB 3.2 Gen 1 headers (up to 4 ports)

• 2 x USB 2.0 headers (up to 4 ports)

---

🎧 Audio

• Codec: Realtek 7.1 High Definition Audio

• Enhancements:

  • Audio shielding

  • Premium audio capacitors

  • Multi-streaming

  • Front panel retasking

  • Up to 24-bit / 192kHz playback support

---

❄️ Cooling Features

• VRM Heatsinks: High-mass aluminum heatsinks

• M.2 Cooling: Dedicated M.2 heatsinks

• Fan Headers: Multiple 4-pin PWM/DC headers

• AIO Pump Header: Yes

• Control Software: Fan Xpert and UEFI fan tuning

---

🧰 DIY-Friendly Features

• Q-LED: Diagnostic LEDs for quick troubleshooting

• Q-DIMM: One-sided RAM latches

• Q-Slot: GPU quick release

• M.2 Q-Latch: Tool-free M.2 installation

• Pre-mounted I/O Shield: Faster, cleaner case install

• BIOS FlashBack™: BIOS updates without CPU, RAM, or GPU

---

📏 Form Factor

• Type: ATX

• Dimensions: 30.5 cm x 24.4 cm

---

🔧 Ideal For

• PC builders seeking next-gen AMD performance, DDR5 memory, PCIe 5.0 SSD support, and onboard Wi-Fi 6 — all in a sleek, professional-grade layout perfect for gaming, productivity, or workstation builds.
