Description
The Aerocool HAVN HS-420 Base Edition is a premium mid-tower case built for enthusiasts who demand both aesthetics and performance. Featuring a dual-chamber hybrid design and a panoramic heat-formed tempered glass panel, it offers stunning component visibility while maintaining excellent airflow and organization. With support for up to 11 fans, 420 mm radiators, and large GPUs, the HS-420 is designed to house the most powerful builds. The Base Edition includes an adjustable GPU support bracket and extensive cable management features, while leaving full customization up to the builder.
Key Features
-
Dual-chamber design for optimal airflow and clean separation of components
-
Heat-formed tempered glass panel with wide panoramic view
-
Adjustable GPU support bracket for heavy or long graphics cards
-
SimpliCable routing system with grooves, trays, pass-throughs, and stabilizers
-
Support for up to 11 fans and triple 420 mm radiators
-
Tool-less drive installation with versatile storage mounting options
-
Premium construction with reinforced steel and tempered glass
Specifications
Form Factor:
-
Mid-Tower Case
Motherboard Support:
-
E-ATX (up to 277 mm width)
-
ATX, Micro-ATX, Mini-ITX
Dimensions:
-
541 × 259.5 × 547 mm
Weight:
-
Approx. 17.8 kg (Base Edition)
Drive Bays / Storage:
-
4 × 3.5″ HDD
-
8 × 2.5″ SSD
Fan Support (fans not included):
-
Top: 3 × 120/140 mm
-
Right Side: 3 × 120/140 mm
-
Bottom: 3 × 120/140 mm
-
Rear: 2 × 120/140 mm (max 30 mm thickness)
-
Total: up to 11 fans
Radiator Support:
-
Top: up to 420 mm
-
Right Side: up to 420 mm
-
Bottom: up to 420 mm
Clearances:
-
GPU Length: up to 480 mm
-
GPU Width: up to 195 mm
-
CPU Cooler Height: up to 185 mm
-
PSU Length: up to 220 mm
Front I/O:
-
1 × USB 3.2 Gen2 Type-C
-
2 × USB 3.2 Gen1 Type-A
-
1 × 3.5 mm Audio Combo Jack
-
Power & Reset Buttons
Materials:
-
SGCC Steel
-
Tempered Glass
-
ABS & Nylon Components
-
Silicon Cable Stabilizers
-
Zinc Alloy & Magnetic Mounts
